Number of phases: 3
Number of poles: 8
Rated voltage: 24
Rated speed: 4000
Rated torque: 0.0625
Rated current: 1.8
Rated power: 26
Peak torque: 0.19
Peak current: 5.4
Back EMF coefficient: 4.1
Torque constant: 0.039
Moment of inertia: 24
Body length: 41
Sensor: Hall
Insulation class: B
Protection class: IP30
Storage temperature: -25~+70C
Working temperature: -15~+50C
Working humidity: 85% RH or below (no condensation) =85% RH
Working environment: outdoors (no direct sunlight), no corrosive gas, no flammable gas, no oil mist, no dust
Altitude: 1000 meters or below
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
