Physical Characteristics
|
|
|
|
Power
|
Removable&Rechargeable 3.85V 5000mAh Li-ion battery
|
|
|
Backlight
|
450 NITS, LED
|
|
|
Network Connections
|
WWAN, Wi-Fi, Ethernet cradle
|
|
|
Interface Ports
|
Bottom USB 2.0 OTG- host/client (Type-C)
|
|
|
Performance Characteristics
|
|
|
|
CPU
|
MTK MT6762, Octa-core Cortex-A53, 2.0GHz
|
|
|
Operating System
|
Android 11.0
|
|
|
RAM
|
3/4GB LPDDR3
|
|
|
Flash
|
32/64GB eMMC 5.1
|
|
|
Interactive Sensor Technology
|
|
|
|
Sensor
|
Proximity Sensor、Light Sensor、Accelerometer、Magnetometer、Gyroscope、
|
|
|
Data Capture
|
|
|
|
Scanning
|
HS7/ SE4710: 2D Standard range omnidirectional imager
|
|
|
Camera
|
Front 5 MP fixed focus; f/2.4 aperture
Rear 13 MP auto focus; f/2.2 aperture; Flash LED |
|
|
NFC
|
High RF output power; ISO15693、ISO14443A/B、MIFARE：Mifare S50,Mifare S70,Mifare UltraLight, Mifare Pro, Mifare Desfire 、FeliCa
Supported cards |
|
|
Wireless WAN
|
|
|
|
WAN Radio Frequency
|
TDD-LTE(B34/B38/B39/B40/B41) FDD-LTE(B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B17/B19/B20/B25/B26/B28A/B28B/B30/B66)
WCDMA(B1/B2/B4/B5/B6/B8/B19) TD-SCDMA(B34/B39) CDMA2000 1x EV-DO Rev.A BC0 (800MHz) CDMA 1x GSM/EDGE/GPRS(850/900/1800/1900) |
|
|
Data Rate
|
GPRS：DL / UL171.2kbps
EDGE：DL / UL384 kbps CDMA1x: DL 153.6kbps/ UL 153.6kbps EVDO: DL 3.1 Mbps / UL 1.8 Mbps DC-HSPA+: DL 42Mbps / UL 5.76 Mbps LTE：DL 150 Mbps (CAT4) / UL 75 Mbps（CAT5) |
|
|
GPS
|
|
|
|
Positioning System
|
GPS L1 with A-GPS: Glonass; BeiDou; Galileo
|
|
|
Wireless LAN
|
|
|
|
Radio
|
IEEE 802.11 ac/a/b/g/n/d/e/h/i/j/k/r/v/w（2.4G/5G Dual band WIFI）
|
|
|
Data Rates
|
5 GHz: 802.11a/n/ac — up to 433 Mbps
2.4 GHz: 802.11b/g/n — up to 200 Mbps |
|
|
Operating Channels
|
CH1-CH13,CH36-CH165
|
|
|
Security and Encryption
|
WEP,WPA/WPA2-PSK,WAPI,WAPI-PSK EAP:EAP-TLS,EAP-TTLS,PEAP-MSCHAPv2,PEAP-TLS,PEAP-GTC,PWD,SIM,AKA
|
|
|
Fast Roam
|
Supports 802.11r Fast Roam
|
|
|
Wireless PAN
|
|
|
|
BT
|
BT 4.1 ,BT Low Energy (BLE);secondary BT BLE beacon for finding lost (powered off) devices
|
|
|
Communication Distance
|
>10m
|
|
|
User Environment
|
|
|
|
Operating Temp.
|
-20℃ to +50℃
|
|
|
Storage Temp.
|
-40℃ to +70℃
|
|
|
Humidity
|
5% to 95% non-condensing
|
|
|
Sealing
|
IP68
|
|
|
Drop Specification
|
1.5m(Concrete Surface)
|
|
|
Tumble Specification
|
1000 round 0.5 meter tumbles（2000 times impact）
|
|
|
Electrostatic
Discharge (ESD) |
+/-15 kV air discharge, +/-8 kV direct discharge
|
|
|
Accessories
|
|
|
|
Standard Accessories
|
Adapter Charger ×1、USB Type-C cable ×1、Rechargeable Battery ×1
|
|
|
Optional Accessories
|
Hand Strap×1 、Single-Slot 、Snap on Trigger Handle
|
|
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
