Six voltage input channel: DC0~10V
Four optoelectronic isolation digital input channel (Low level input)
Four optoelectronic isolation digital output channel (NPN collector output)
RS485 MODBUS RTU standard communication protocol
Netted with configuration software, PLC or industry touch panel
Communication, digital input and digital output status LED
Communication circuit designed for thunder protection and interference immunity
Used for signal collection and control in industrial field
2.Specification
Analog input channel 6ch
Analog input range DC0~10V
Analog input accuracy ±0.02V
Digital input channel 4ch (Low level input)
Digital output channel 4ch (NPN collector output, 500mA)
Working temperature -20~70℃
External power supply DC9V~30V/2W
Isolation protection DC1500V
Installation method Standard DIN slide rail or screw
Dimension 125×73×35mm
