Water pressure resistance: 1.75MPa
Voltage and current: DC4.524V, working current ≤10mA
Insulation resistance 100MΩ
Output pulse high level: greater than or equal to 4.5V (input voltage DC 5V)
Output pulse low level: less than or equal to 0.5V (input voltage DC 5V)
Pulse duty cycle: 50%
Flow pulse characteristics: (0.55*Q)±5%, F:Hz, Q=L/min±5%10,
Accuracy: ±3~5%
Note: 1. Please do not disassemble it yourself when you find that the product has quality abnormalities. 2. If you want to use air to dry the remaining water in the sensor, please note that the output signal must be less than 150HZ, and the impeller cannot rotate at high speed without water.
Lead wire method:
Red IN is connected to the positive pole
Black GND connected to negative pole
