AXP120-X67 Fan Cooler 67mm Thin Pure Copper Push Down CPU Cooler Suitable For ITX Small A4 Case For LGA1700 115X 1200 2011 AM4
Product parameters
product code：BG685K
Radiator size: L123.5mm * W 120mm * H 52mm
Radiator material: aluminum fins + pure copper heat pipe with nickel plating
Product weight: 490g
Tight matching process: reflow soldering copper bottom through FIN
Supported platforms: Intel: LGA 115X/1200/1700/2011/2066 AMD: AM4
Fan size: L 120mm * W 120mm* H 15mm
Fan weight: 120g
Fan speed: 1800 RPM±10%
Fan noise: ≤26.1 dBA
Fan air volume: 59 CFM
Fan pressure: 1.36mm/H:O(MAX)
Fan interface: 4PIN PWM
Working voltage: 12V DC
Product Description
*According to the characteristics of instantaneous CPU heating power consumption, high peak value, and low standby limit, the single heat pipe of the module is independently adjusted on the basis of the AGHP heat pipe. The use of different heat pipe power ratios makes the overall heat dissipation power consumption of the radiator form a wide range of heat dissipation and greatly increases the upper limit of heat dissipation
*AGHP technology: Vertical radiator is a common chassis installation method, adopting
Use the new heat pipe process to solve the problem of slow performance of thermal capillary reflow affected by gravity.
Enables radiator performance in vertical orientation to optimize performance
*The TPC data of heat dissipation power consumption of the radiator comes from the thermal power heating platform, which is not related to the nominal TDP of the CPU. The actual heat dissipation rate varies with the platform, and the actual measurement shall prevail.
*AGHP GEN3: Further optimization on the AGHP technology, based on different module structures and heat source center points, the upper limit of the power of a single heat pipe position is set differently
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
