item
|
value
|
|
Model Number
|
CAX60H1212E12R4G
|
|
Type
|
ABSOLUTE ENCODER
|
|
Place of Origin
|
China
|
|
|
Shanghai
|
|
Brand Name
|
CALT
|
|
Usage
|
speed and angle sensor
|
|
Theory
|
optical sensor
|
|
Output
|
RS485
|
|
Description
|
absolute encoder
|
|
Outer dia
|
60mm
|
|
Shaft Diameter
|
12mm
|
|
resolution
|
12bits
|
|
power supply
|
10~30vdc
|
|
output
|
RS485
|
|
Current Consumption
|
80mA (24V power supply) no load
|
|
Linearity Resolution
|
1/4096
|
|
Operating Temperature
|
-25-80℃
|
|
Programming temperature range
|
0℃~+70℃
|
|
Storage Temperature
|
-40-80℃
|
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
