Features:
* Using laser sensor, direct measurement, more convenient than mechanical sensor.
* The size of the split sensor is small, which is suitable for measuring in a narrow space.
* Two kinds of sensors selectable, the integrated sensor and the split sensor.
* Metric or imperial units can be used to display readings.
* With automatic power off function.
Measuring Principle:
This tensiometer can measure the natural vibration frequency of the belt through the emission and reception of the laser, and then calculate the tension value of the belt by combining the input belt mass and the free belt length.
Specifications:
Measurement Range
10Hz~800Hz
Input Range
Free Belt Length Max 99.99m
Belt Mass Max 9.999kg/m
Digital Sampling Error
<1%
Display Error
±1Hz
Total Error
<5%
Operating Temperature Range
+10°C~50°C
Transportation Temperature Range
-5°C~70°C
Unit of Measurement
Metric: m, kg/m, N
Imperial: Inch, lbs/foot, lbf
Optical Path Measurement Distance
3mm~20mm
Depth of Split Sensor
About 66mm
Power Supply
4x1.5V AAA (UM-4) Battery
Size
Main Unit: 178mmx72mmx34mm
Sensor: 124mmx2mm1x12mm
Weight
180g (Not Including Battery)
Standard Accessories
Main Unit
Split Sensor
Carrying Case (B04)
Operation Manual
