Emax Babyhawk II Analog 3.5Inch ECO1404 3700KV F4 4in1 25A ESC TBS UNIFY PRO32 5G8 V1.1 RunCam Racer 5 FPV Racing Drone PNP/BNF

  Specification:

Babyhawk I (Analog):

  Parameter

Diagonal wheelbase (without paddles): 155mm

Maximum size of the aircraft (without antenna, cable tie): 210mm

Aircraft weight (without battery): 117g±2g

Motor: ECO1404-3700KV

Propeller: Avan 3.5 inch Propeller

Main Flight Controller: F4 ( STM32F411 firmware) 4in1 25A ESC

Camerar: TBS UNIFYPRO32 5G8 VTX + RUNCAM Racer 5

  Package Included:

1x Babyhawk I(Analog)

1x Instruction manua card

2x Extra Propeller (CW & CCW)

1x Screw pack

  LiteRadio 2 SE Radio Transmitter is the upgraded version based on LiteRadio 2 and comes with huge improvements.

     Built-in 1000 mAh 1S battery, LiteRadio 2 SE increases the endurance to 8 hours.   Pilots can directly operate the Joystick Calibration and Upgrade Firmware on the radio transmitter.   Supports the Frsky / Futaba / Bayang, pilots can easily change Futaba, Frsky D8, Frsky FCC D16 and Frsky LBT D16 mode via the radio transmitter.   Comes with 100mW transmitting power, LiteRadio 2 SE brings a wider operating range.

   Bullet Point

   LiteRadio 2 SE upgrades with Customized LiteRadio System. Pilots can directly operate the Joystick Calibration and Firmware Update on the radio transmitter, which is more convenient for the beginner racer to operate.   Equipped with a built-in 1000 mAh 1S battery, LiteRadio 2 SE can use up to 8 hours, bringing an excellent endurance performance.    Comes with a built-in charging module, LiteRadio 2 SE can support USB charging which is more convenient to use. Meanwhile, it designs a Low-Power warning to indicate a low battery. While it needs to be re-charged(when the voltage is lower than 3.5V), the LED will turn red first, then it will turn blue and flash slowly.    Compared with the LiteRadio 2, LiteRadio 2 SE has a larger transmitting power that can reach 100mW, bringing a wider operating range.   Adopted the rubber coat, LiteRadio 2 SE is ergonomic and has the shape of a gaming controller. It's comfortable to hold, and the anti-slip texture on the handles allows for a solid grip.   This radio transmitter acts as a USB Joystick when connected to a personal computer. So you could use it to play FPV simulators like EREADRONE.   LiteRadio 2 SE transmitter has been equipped on the Ready-to-Fly FPV whoop racing advanced kit 2 and FPV whoop racing starter kit 2. It is one of the easiest ways to get into the hobby.

   Specification

   Item: LiteRadio 2 SE   Color: White   Frequency Range: 2.4G (2403MHz-2447MHz)   2.4G System: NRF24L01 or CC2500   Channel: 8   Support Protocol: Bayang / Futaba S-FHSS / Frsky FCC D16/ Frsky LBT D16 / Frsky D8   Power: ≤100mw   Adapted Drone Type: Multirotor   Support USB Charging / Firmware Update   Support BETAFPV Simulator Connected / Customized LiteRadio System / Joystick Calibration   LED Light: Green-Power On / Red-Warning if the voltage is lower than 3.5V / Blue-Normal   Battery: Built-in 1000mAh 1S Battery   Charging Connector: TypeC

   Comparison of LiteRadio 2 SE and LiteRadio 2

         LiteRadio 2 SE        LiteRadio 2                      System        Customized LiteRadio System        Opensource OPENTX                      Power        Built-in 1000mAh 1S Battery        Removable 350mAh 2S Battery                      RF Power        100mW        80mW                      Working Time        8 Hours        3 Hours                      Protocols        Frsky FCC D16/Frsky LBT D16/Frsky D8/Futaba S-FHSS, Bayang        Frsky FCC D16/Frsky LBT D16 /Frsky D8, Bayang                      Joystick Calibration        Yes        No(Could with OpenTX Companion)                      Firmware Update        Yes        No

   How to switch the protocol

            To change protocols (Frsky FCC D16, Frsky LBT D16, Frsky D8, or Futaba S-FHSS     ), you have to power it off first, then press and hold the bind button while you power it back on. After that, the flash times of the red LED before buzzer alarms will change, and it will      indicate which protocol it is on.

                                          LED Status         Protocol Version                         Flash Once         Frsky FCC D16                         Flash Twice          Frsky LBT D16                         Flash Three Times          Frsky D8                         Flash Four Times         Futaba S-FHSS

   Diagram of LiteRadio 2 SE

   Package

   1 * LiteRadio 2 SE Radio Transmitter   1 * User Manual
