Specifications:
Functions: vehicle DC dark current, leakage current, etc., other AC/DC current, leakage current measurement
Power supply: zinc manganese dry battery 6F22 9v, continuous use for 30 hours
Test mode: clamp CT, non-contact measurement
Jaw size: 16mm × 18mm
Range: 0mA - 60.0A AC/DC
Resolution: 1mA AC/DC
Precision: ± 2% rdg soil 5dgt (23 ℃± 5 ℃, below 75% rh)
Display mode: 4-bit LCD display
Instrument size: height, width and thickness: 215mm × 61mm × 32mm
LCD size: 35mm × 21.5mm; Display field: 32mm × 15mm
Sampling rate: 2 times/second
Frequency response: AC: 45Hz~400Hz
Polarity indication: automatic identification and display of "_" during DC current detection number
Wire position: the detected wire is in the center of the jaw
Gearshift: fully automatic switching
Line voltage: 600V and below line test
RS232 interface: with RS232 interface, the stored data can be uploaded to the computer for saving and printing
Communication parameters: baud rate 9600, data bit 8, stop bit 1, check bit NONE
Data storage: 99 groups, flashing "FULL" symbol indicates that the storage is full
Data retention: data retention function: "DH" symbol display
Overflow display: Overrange overflow function: "OLA" symbol display
Automatic shutdown: the instrument automatically shuts down 5 minutes after startup to reduce battery consumption
Battery voltage: When the battery voltage drops to 7.2V, the low battery voltage symbol will be displayed to remind you to replace the battery
Instrument weight: 220g (including battery)
Working current: Max 20mA
Operating temperature and humidity: - 10 ℃～ 50 ℃; Below 80% rh
Limit temperature error: - 10 ℃～ 0 ℃ and 40 ℃～ 50 ℃, with maximum error increase of 2% rdg
Storage temperature and humidity: - 10 ℃～ 60 ℃; Below 70% rh
Insulation strength: AC 3700V/rms (between iron core and box)
Applicable safety regulations: IEC1010-1, IEC1010-2-032, pollution level 2, CAT III (600V)
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
