Holybro Kopis Cinewhoop2.5 KISS AIO FPV Drone 4S BNF W/ FC Firmware FETtec Mini 15A ESC F1404 KV3800 Motor Caddx Polar Vista
Features
Flight Controller & ESC:
Holybro-FETtec Mini AIO 15A
KISS FC Firmware
Caddx Polar Vista Kit Digital HD FPV system (Optional)
Motor: F1404 KV3800
Propeller: Gemfan D63-3B
Frame: 3mm 3k carbon fiber
Receiver: TBS Crossfire Nano (Optional)
Battery plug: XT30
Wheelbase: 105.5mm
Weight: 155.2g（Without Battery）
Take-off Weight: 249g (4s 850mah Lipo)
Recommend battery (Not Included): 550~850mah 4s
Holybro-FETtec Mini AIO Specifications
FC:
KISS FC firmware
F3 Processor (STM32F303CCT6 @ 72MHz (MPU6000))
Supply voltage 6-18V (2S-4S Lipo voltage)
Dedicated onboard 5V BEC (max 1A)
ESC:
Active current limiting @ 15A
Input voltage: 2S-4S
High quality 30V MOSFETs
STM32G071 @ 64MHz
128 kHz Motor PWM
Automatic input signal detection
Dshot 300-2400
PWM
OneShot42/125
OSD:
Graphic OSD (STM32)
Full KISS Tuning
Filter (PIDs, Rates, Settings)
LED control (RGB LED, Racewire)
VTX
Live data graphs (Voltage, motor rpm, current, motor temp, gyro values, link quality)
KISS GPS support + live map
Custom graphic pilot logo
Stick overlay
Custom layout
The FETtec Mini AIO 15A works with KISS/FETtec FC firmware version 1.3RC45Y or later
Includes:
1x Kopis cinewhoop2.5” FPV racing drone
1x Insta360 GO 2 camera mount
1x Naked GoPro/SMO4k camera mount
2x Propeller guard
Naked Gopro & SMO-4K Mount
Updated:
1.Flight Controller: Kakute H7 Mini
2.Digital HD Camera:Caddx Polar Vista Kit starlight Digital HD FPV system
3.ESC:Tekko32 F4 4in1 mini 45A ESC
Features:
Frame:3mm 3k carbon fiber
Flight Controller: Kakute H7 Mini
ESC: Tekko32 F4 4in1 45A mini ESC
VTx:Caddx Polar Vista Kit starlight Digital HD FPV system
Motor: F1404 KV3800
Propeller: D63-5B
Buzzer included.
Battery plug: XT30
Wheelbase: 105.5mm
Weight:159g（Without Battery）
Take-off Weight:250g (4s 850mah Lipo )
Recommend battery (Not Included): 550~850mah 4s
Specifications:
FC:Kakute H7 Mini
ESC:Tekko32 F4 4in1 45A mini ESC
F4 MCU with BLHELI32 firmware
Maximum PWM output upto 96K (default 48K)
Amperage meter scale ratio has been adjusted to 168.
PWM input, TLM supported
Voltage output (VBAT)
NO output BEC
Supports oneshot / Multishot / Dshot PWM
Supports damped light
Supports 3-6S lipo input
Ext. cap needed for 6s (1000uf 35v for 6s usage.)
Mounting holes: 20x20mm(M3)
Size:30 x 39 mm
Weight: 7.2g
Includes:
1x Kopis cinewhoop2.5” FPV racing drone
Caddx Polar Vista Kit starlight Digital HD FPV system (Optional)
1x Naked GoPro camera mount
4x D63-5B Propeller
2x Propeller guard
Please note: Starting from April 12th, 2022, all Kopis BNF will no longer include the Kopis Carry case.
(Package doesn’t include Insta360 GO, the Insta360 GO on the pictures for reference only.)
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
