Feature
1. Based on the pluggable non-preset tube technology
2. Precision ceramic components with co-axial self centering, Excellent and durable optical property
3. Optical fiber fits axially in elastic way and avoids completely any false connect
4. Triple clamping through the naked fiber, tight buffer and cable, etc., can be used as patchcord
5. High on-line tensile strength of Optical Fast Connector after terminating, always keep connecting under the force from cabling and drawing.
6. Integrated protection of the casing to withstand harsh user environment.
7. Directly connectable with ONU without any optical socket, which reduces FTTH cost.
8. High success rate and easiness in installation with average splicing time 100 sec
9. Lower requirement for the habit working and work environment call for to the builder.
10. Visible Installation quality; independent from any far end light source and special device satisfying cabling construction in any sectioned way.
Specification
ITEM
Technical Parameters
Applicable for
3.1 x 2.0 mm Drop cable
Optical fiber diameter
125μm ( 657A & 657B )
Tight buffer diameter
250μm
Fiber mode
Single mode
Operation time
About 100s(no fiber cut)
Insert loss
≤ 0.3dB(1310nm & 1550nm)
Return loss
≥40dB
Fastening strength of naked fiber
>5 N
Fastening strength of naked fiber holder
>10 N
Tensile strength
>50 N
Using temperature
-40~+80°C
On-line tensile strength (20 N)
IL ≤ 0.2dB RL ≤ 5dB
Mechanical durability (500 times)
IL ≤ 0.2dB RL ≤ 5dB
Drop-off test (drop-off height 4m,
once per direction, totally 3 times)
IL ≤ 0.2dB RL ≤ 5dB
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
