IO/Sensor/Navigation
|
|
|
|
|
||||
|
SIM Card
|
Micro SIM
|
|
|
|
||||
|
Data interface
|
Magnetic interface（Pogo pin）USB&data
|
|
|
|
||||
|
RFID module
|
132K animal tags
|
|
|
|
||||
|
Gravity sensor
|
support
|
|
|
|
||||
|
Motion sensor
|
support
|
|
|
|
||||
|
Direction Sensor
|
Support
|
|
|
|
||||
|
Magnetic Field Sensor
|
Support
|
|
|
|
||||
|
Gyro sensor
|
Support
|
|
|
|
||||
|
Rotation Vector
|
Support
|
|
|
|
||||
|
Light-sensor
|
Support
|
|
|
|
||||
|
Acceleration sensor
|
Support
|
|
|
|
||||
|
Charger
|
5.0V 2A-10W
|
|
|
|
||||
|
Navigation
|
GPS+Beidou+Glonass+AGPS+SBAS （EPO 2.5m）
|
|
|
|
||||
|
Appearance
|
|
|
|
|
||||
|
Size
|
267*100*38mm（L×W×H）
|
|
|
|
||||
|
Weight
|
447g
|
|
|
|
||||
|
Color & Material
|
gray (Metal & ABS)
|
|
|
|
||||
|
Communications & Networking
|
|
|
|
|
||||
|
Phone Call
|
GSM /WCDMA/CDMA 1X/VoLTE
|
|
|
|
||||
|
2G
|
GSM/CDMA 1X/EDGE/GPRS/WAP
|
|
|
|
||||
|
2G Band
|
GSM（B2/3/5/8）
|
|
|
|
||||
|
3G
|
WCDMA 3.75G (HSDPA+ 42.2Mbps, HSUPA+ 11.5Mbps)
|
|
|
|
||||
|
3G Band
|
WCDMA (B1/2/5/8)
|
|
|
|
||||
|
4G
|
FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink, 50Mbps uplink
|
|
|
|
||||
|
4G Band
|
TD-LTE (B38/39/40/41); FDD LTE (B1, B2, B3, B4, B5, B7, B8, B12, B17, B20, B28)
|
|
|
|
||||
|
WI-FI
|
Dual-band (2.4GHz/5Ghz) single stream 802.11 a/b/g/n/ac
|
|
|
|
||||
|
Bt
|
5.0 Low Energy (LE)
|
|
|
|
||||
|
Industrial & Reliability Design
|
|
|
|
|
||||
|
Shake-proof
|
1-19Hz/1.0mm; 19-200Hz/1.0g
|
|
|
|
||||
|
Dropproof /IK
|
MIL-STD-810G/Method516.6/Procedure IV & Touch Panel IK05
|
|
|
|
||||
|
Waterproof
|
Class 5 ( IEC 60529 )
|
|
|
|
||||
|
Dustproof
|
Class 6 ( IEC 60529 )
|
|
|
|
||||
|
Reliability
|
MTBF>5000h；MTTR＜0.5h
|
|
|
|
||||
|
Operating
|
-20°C to 55°C
|
|
|
|
||||
|
Storage Temperature
|
-40°C to 80°C
|
|
|
|
||||
|
RH
|
5% to 95%
|
|
|
|
||||
|
Operating Altitude
|
Max: 4,500 m（15,000 feet）
|
|
|
|
||||
|
Certification/OS/Software
|
|
|
|
|
||||
|
Language
|
English, Spanish, Portuguese (Brazil), Portuguese (Portugal), Italian, German, Dutch, French, Polish, Romanian, Turkish,
|
|
|
|
||||
|
OS
|
Andriod 10
|
|
|
|
||||
|
Package/Warranty terms
|
|
|
|
|
||||
|
Warranty
|
24 months
|
|
|
|
||||
|
Package
|
USB cable/Charger 5V 2A/Introduction manual/Screen protector/ Packing box
|
|
|
|
||||
|
HF RFID/NFC
|
|
|
|
|
||||
|
Frequency
|
13.56MHz
|
|
|
|
||||
|
Protocol standard
|
ISO14443A/B, ISO15693, NFC
|
|
|
|
||||
|
Label standard
|
M1(S50, S70), CPU, NFC
|
|
|
|
||||
|
Read-write distance
|
2-5cm
|
|
|
|
||||
|
132K LF RFID （support Animal tags）
|
|
|
|
|
||||
|
Operation Frequency
|
132 kHz
|
|
|
|
||||
|
support agreement
|
ISO11784/5
|
|
|
|
||||
|
Read distance
|
>30cm
|
|
|
|
||||
|
Working mode
|
FDX-B/HDX
|
|
|
|
||||
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
