Features:

100MHz bandwidth.

1GS/s sample rate.

Time base range: 2ns/div~100s/div.

3.5ns rise time.

2 channels.

7.0-inch high resolution LCD display.

Support for SCPI and LabVIEW.

  Specifications:

          Functions & Specifications of SDS1102

          Bandwidth

    100MHz

          Sample Rate

    1GS/s

          Horizontal Scale(s/div)

    2ns/div - 100s/div, step by 1-2-5

          Rise Time (at input, typical)

    ≤3.5ns

          Channel

    2

          Display

    7" color LCD, 800 × 480 pixels

          Input Impedance

    1MΩ ± 2%, in parallel with 20pF ± 5pF

          Channel Isolation

    50Hz:100:1, 10MHz:40:1

          Max Input Voltage

    400V (PK-PK) (DC+AC, PK-PK)

          DC Gain Accuracy

    ±3%

          Record Length

    10k

          DC Accuracy (average)

    Average≥16: ±(3% reading+0.05div) for △V

          Probe Attenuation Factor

    1X, 10X, 100X, 1000X

          LF Respond (AC, -3dB)

    ≥10Hz (at input, AC coupling, -3dB)

          Sample Rate / Relay Time Accuracy

    ±100ppm

          Interpolation

    sin (x) / x

          Interval(△T) Accuracy (full bandwidth)

    Single: ±(1 interval time + 100ppm × reading + 0.6ns),

Average＞16: ±(1 interval time + 100ppm × reading + 0.4ns)

          Input Coupling

    DC, AC, and GND

          Vertical Resolution (A/D)

    8 bits (2 channels simultaneously )

          Vertical Sensitivity

    5mV/div - 5V/div (at input)

          Trigger Type

    Edge, Video

          Trigger Mode

    Auto, Normal, and Single

          Trigger Level

    ±5 divisions from screen center

          Line / Field Frequency (video)

    NTSC, PAL and SECAM standard

          Cursor Measurement

    △V, and △T between cursors

          Automatic Measurement

    Vpp, Vavg, RMS, Frequency ,Period, Vmax, Vmin, Vtop, Vbase, Width, Overshoot,

Pre-shoot, Rise time, Fall time, +Width, -Width, +Duty, -Duty, Delay A→B , Delay A→B

          Waveform Math

    +, -, ×, ÷, invert, FFT

          Waveform Storage

    16 waveforms

          Lissajous Figure Bandwidth

    full bandwidth

          Lissajous Figure Phase Difference

    ±3 degrees

          Communication Interface

    USB host, USB device

          Frequency Counter

    available

          Power Consumption

    ＜15W

          Fuse

    2A, T class, 250V

          Power Supply

    220V (EU/UK plug), 110V (US plug), 50/60Hz, CAT II

          Plug Type

    EU / UK / US (Optional)

          Item Size

    300 * 76 * 153mm / 11.81 * 2.99 * 6.02in

          Net Weight

    1403g / 3.09lb

          Package Weight

    1601g / 3.53lb

          Package Size

    37 * 18 * 11.5cm / 14.57 * 7.09 * 4.53in

  Package List:

1 * Oscilloscope

2 * Oscilloscope Probe

1 * Oscilloscope Powerline

1 * Data CD

1 * USB Cable

1 * Package of Accessory

1 * Quick Guide (English)

  Note:

Please read the instruction manual in CD carefully to avoid injury and prevent damage to this product.
