CHARACTERISTIC PARAMETERS |
||
|
Product Model |
HS4-O-800 |
|
|
input |
Maximum Input Power |
800W |
|
Operating voltage range |
14~65V |
|
|
MPPT Voltage Range |
14~65V |
|
|
Maximum input Current |
17A |
|
|
Over-temperature Protection |
160鈩� |
|
|
Conversion Efficiency |
Peak Conversion Efficiency |
99.2% |
|
Power Consumption @26V |
0.8W |
|
|
Power Consumption @36V |
1.3W |
|
|
Power Consumption @46V |
1.8W |
|
|
Specifications |
Dimensions(L*W*H) |
107*105*22mm |
|
Weight |
505g |
|
|
Cable |
4.0mm² |
|
|
Connector |
MC4 or compatible MC4 |
|
|
Operating Temperature Range |
|
|
|
Protection Degree |
IP68 |
|
|
Design Standard |
Designed Life |
25 Years |
|
Quality Commitment |
10 Years |
|
|
Functiom |
Standard Features |
Optimization |Anti-Hotspot |
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
