Specfications
MICROPHONE PREAMPLIFIER:
GAIN RANGE:
58dB
LINEUP:
12dBu = 0dBFS
MIC MAX INPUT LEVEL:
12dBu
MAX INPUT LEVEL:
21dBu
INPUT IMPEDANCE (Mic):
2.8k
INPUT IMPEDANCE (Line):
>8k
THD+N @ 0dBu
0.00%
SNR:
101dBu A-Weighted
EIN:
129dB A-Weighted
CMRR @ 1k:
>75dB
CROSSTALK:
>-100dB
FREQUENCY RESPONSE – MIN GAIN
±0.5dB 10Hz to 40kHz
XLR COMBI FEMALE:
Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4” TRS JACK:
Tip (Hot), Ring (Cold) & Sleeve (Shield)
D.I / Instrument Input
RANGE:
40dB
LINEUP:
12dBu = 0dBFS
THD+N @ 0dBu:
0.1%
SNR:
100dBu A-Weighted
FREQUENCY RESPONSE – MIN GAIN
±0.5dB 10Hz to 20kHz
1/4” TS JACK:
Tip (Hot) & Sleeve (Shield)
ANALOGUE TO DIGITAL CONVERTER
THD+N @ -1dBFS:
0.001%
DYNAMIC RANGE:
120dB A-Weighted
CMRR:
>80dB
FREQUENCY RESPONSE:
±0.5dB 10Hz to 40kHz
Line Outputs (DAC):
LINEUP:
12dBu = 0dBFS
THD+N @ -1dBFS:
0.0006%
DYNAMIC RANGE:
125.5dB A-Weighted
CROSSTALK:
>120dB
FREQUENCY RESPONSE:
±0.1dB 10Hz to 40kHz
1/4” TRS JACK:
Tip (Left), Ring (Right) & Sleeve (Shield)
HEADPHONE OUTPUTS:
LINEUP:
18.5dBu = 0dBFS
THD+N @ -1dBFS:
0.0009%
DYNAMIC RANGE:
125.5dB A-Weighted
CROSSTALK:
>116dB
FREQUENCY RESPONSE:
±0.25dB 10Hz to 40kHz
MAXIMUM LEVEL @ 30R:
2.59V Peak, 1.827V RMS, 223mW
MAXIMUM LEVEL @ 62R:
4.18V Peak, 2.95V RMS, 280mW
MAXIMUM LEVEL @ 600R:
7.72V Peak, 5.46V RMS, 100mW
1/4” TRS JACK:
Tip (Left), Ring (Right) & Sleeve (Shield)
USB-C High Speed:
BUS POWER:
MIN REQUIREMENT:
0.9A @ 5V
>=USB 3.0 Port
MAX REQUIREMENT:
1.5A @ 5V
USB-C: Provides higher headphone outputs levels
No. of INPUT CHANNELS:
10
No. of OUTPUT CHANNELS:
16
DSP MIXER LATENCY ROUND TRIP (in-to-out):
44.1kHz
0.65mS
48.0kHz
0.6mS
88.2kHz
0.33mS
96.0kHz
0.31mS
Products Description
Features
*2 x Audient Console Mic Preamps *Class Leading Converters *1 x JFET Instrument Input *4 x Line Outputs *Dual Headphone Outputs *ADAT Input for Expandability *Ultra Low Latency Software Mixer *Advanced Monitor Control *Scrollcontrol *True Phantom Power over USB *USB3.0 Bus Powered *All Metal Design *Free Software + Plugins
