| System Configuration | |
| CPU | ARM Cortex-A53 64-bit Quad-core processor 2.0GHz |
| OS | Android 9.0 |
| Memory | 1GB RAM + 16GB ROM (Optional 2+16, 3+32, 4+64) |
| Expansion Slot | PSAM x 2; TF x 1; Micro SIM x 2; POGO Pin x 1; Type -C x 1 |
| Display | 3.2 inch IPS display with 480×800 resolution |
| Touch Panel | Support multi-touch, support wet hand and glove operation |
| Camera | Rear: 13MP, front: 5MP, auto focus with LED fill light |
| Imager Window | Corning Gorilla |
| Keyboard | 30 keys in total, front keys 26, side keys 4 |
| Battery | 4.35V 5200 mAh Lithium polymer battery |
| Audio Frequency | Built-in microphone |
| Prompt | Vibration Tip/LED Tip/Audio Tip |
| Vibration Motor | Built-in programmable vibration motor |
| Size & Weight | 182.49mm x 65.56mm x 25.59 mm, 320g (including battery) |
| Communication Transmission | |
| WWAN |
2G:GSM(850/900/1800/1900MHz) 3G:WCDMA (850/900/1900/2100MHz) 4G:TDD-LTE (B38/B39/B40/B41) 4G:FDD-LTE (B1/B3/B5/B7) |
| WLAN | Wi-Fi 802.11a/b/g/n |
| WPAN | 4.0 (transmission distance: 5~10 meters ) |
| GPS | Support GPS/AGPS,BDS |
| Data Collection | |
| 1D Scannning |
Optical resolution ≥ 4 mil, scanning depth of field 3.81 cm - 60.98 cm, scanning angle 47 ° ± 3 ° (standard), scanning speed 102 times ± 12 times per second (compatible with mainstream brands) 1D: UPC/EAN/JAN, GS1 DataBar, Code 39, Code 128, Code 32, Code 93, Codabar/NW7, Interleaved 2 of 5,Code 2 of 5, Matrix 2 of 5, MSI, Telepen, Trioptic, China Post, etc. |
| 2D Scannning |
Optical resolution ≥ 3 mil, optical resolution omnidirectional, scanning speed 300 times/s 1D: Can read 1D barcodes; 2D: PDF417, MicroPDF417, GS1 Composite, Aztec Code, Data Matrix, QR Code, Micro QR Code, MaxiCode, Hanxin code, etc. |
| RFID | NFC: support 13.56 MHz; support ISO14443A/14443B/15693 protocol, reading distance: 2~5cm |
|
UHF: support 840-960MHz UHF RFID, reading distance: 2 meters Supports reading and writing of EPC C1/G2, 18000-6C protocol cards and tags |
|
| Peripheral Equipment & Accessories | |
| Standard Accessories | Battery, power adapter, USB cable, hand strap |
| Charging Interface | 1 Type-C interface |
| Optional Accessory | Charging cradle |
| Use Environment | |
| Development Tool | Android Studio+Eclipse |
| Programming Language | Java |
| Operating Temperature | -25℃ ~ 55℃ |
| Storage Temperature | -40℃ ~ 70℃ |
| Humidity | 5% ~ 95% (non-condensation) |
| Drop spec | Multiple 1.2m drops to tile over concrete |
| Sealing | IP65 |
