Features:

Embedded bar code scanner, support scan 1D/2D/QR code, compatible with various software, suitable for different terminal systems, efficient use.

Using CMOS image scanning technology, it can scan paper code and screen code, high-performance decoding chip, no fear of incomplete and fuzzy bar code.

Solid insulation process design, to isolate the external damage to the module, not only protect the scanner, but also to protect the safety of users.

The scanning light is soft, and there is no need to worry about the threat of scanning optical fiber to human health. The large window design can easily interpret the larger barcode.

Modular design, tailored for self-service equipment, compatible with Windows XP/Vista/7/8/10, widely used in gate machine, ticket check, mobile payment, etc., easy to use.

Decode Capability: Smoothly scan and decode one-dimensional code(EAN-13, EAM-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code128, Codc93, ITF-6, ITF-14, Interleaved 2 of s.Industrial 2 of 5, Standard 2 of s, Matrix 2 of5, GSI Databar(RSS-Expand, RSS-Limited, RSS-14), Code 39(Code 39 FULL ASCII), Code I1, MSI-Plessey, Plessey, etc.) and two-dimensional code(PDF417, Data Matrix, QR Code).

Specifications:

Color: Black

Material: ABS

Optical Resolution: 752*480 CMOS

MPU: IOTC 0370 CHIP

Scanning Window Size: 46.5 * 31.5mm

Scanning Mode: Inductive Reading

Scanning Speed: 200 times/s

Scanning Accuracy: 10mil

Light Source: White LED

Brightness: 0-100,000 LUX

View Angle: Horizontal 63.7°, Vertical: 70°

Decode Type:

--1D: EAN-13, EAM-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code128(Including FNC1, FNC2, FNC3 subset), Codc93, ITF-6, ITF-14, Interleaved 2 of s.Industrial 2 of 5, Standard 2 of s, Matrix 2 of5, GSI Databar(RSS-Expand, RSS-Limited, RSS-14), Code 39(Including Code 39 FULL ASCII), Code I1, MSI-Plessey, Plessey, etc.

--2D: PDF417, Data Matrix, QR Code

Input Voltage: AC 100-240V, 50/60Hz

Output Voltage: DC 5V, 0.5A

Power Consumption: 1.75W

Interface: USB 1.1(HD-KBW, HID-POS)

Compatibility: Windows XP/Vista/7/8/10

Working Temperature: -10-50℃

Working Humidity: 5-95%(No Condensation)

Storage Temperature: -20-60℃

Item Size: 78.2 * 67.2 * 52.3mm/ 3.1 * 2.6 * 2.1in

Item Weight: 120g/ 4.2oz

Package Size: 17 * 9.4 * 6cm/ 6.7 * 3.7 * 2.4in

Package Weight: 192g/ 6.8oz

Packing List:

1 * Barcode Scanner

1 * USB Cable

1 * User's Manual
