Model
ET430B
ET430
Measurement frequency
100Hz, 120Hz, 1KHz, 10KHz
100Hz, 120Hz, 1KHz, 10KHz, 40KHz, 100KHz
Accuracy
0.30%
0.30%
Display screen
2.8-inch TFT LCD screen
Display digits
Main parameter: 5 bits, minor parameter: 5 bits
Measured parameters
Main parameters: L/C/R/Z, minor parameters: X/D/Q/ theta /ESR
Electrolytic capacitor model
No
Yes
DCRmodel
No
No
Measurement range
L:0.000μH~2000H, C:0.000pF~20.000mF, R:0.0001Ω~200.00MΩ
Measuring display
1 time/second (slow), 2 times/second (medium), 4 times/second (fast)
Internal bias
No
No
Test level
0.6Vrms
0.6Vrms
Calibration function
Open circuit calibration, short circuit calibration
Screening function
The screening limit range can be set from 1% to 50%, with fixed points of 1%, 5%, 10% and 20%
Deviation measurement
Used to compare the percentage deviation between the component and the set nominal value and display
Other
Adjust backlight brightness, automatic shutdown time can be set, Chinese and English can be selected, USB Device communication
Fittings
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
