Operating Information
1. Connect the power adaptor to the power supply outlet. 2. Connect the pH or ORP electrode to the probe inset of the instrument. Remove the protective cap. 3. Turn on the meter. 4. Immerse the electrode in the solution to be tested. Stir gently and wait for the reading to stabilize. 5. Press the "C /F " key, choose the"C /F"for measuring. Press the "MODE "key, choose in turn show EC, CF, TDS for measuring. 6. When you connect the OPR electrode, Please press the "MV" key, it will show the OPR value. 7. Turn off the meter after the measurement. Rinse the electrode with tap water to minimize contamination. Replace the protective cap.
Technical parameters
Measurement index & Range
PH:0.00~14.00 PH
Temperature:-50°C~70°C (-58°F~158°F)
EC:0.00~19.99EC
CF:0.0~199CF
TDS:10~19990ppm
Resolution
PH:0.01PH
Temperature:0.1°C(0.2°F)
EC:0.01EC
CF:0.1CF
TDS:10ppm
Accuracy
PH:±0.1 PH
Temperature:1.0°C
EC,CF,TDS:±2%F.S
Automatic temperature compensation
0°C~50°C
Operating temperature:
0°C~50°C
Operating voltage:
AC110~240V
Size: 155mm×86mm×22mm
Weight: 223g
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
