Holybro Kopis Cinematic X8 396mm 7inch Carbon Fiber Frame Kit 8PCS T-motor F90 KV1300 Motor Gemfan 7040 Propeller ARF Combo Compatible DJI AIR UNIT&CADDX Vista HD digital VTX
Holybro kopis cinematic X8 is a powerful and heavy-duty model designed for professionals. With a full carbon fiber frame which provides a good shock absorption performance, Kopis Cinematic X8 offers a perfect platform with adjustable installation angle available from 0 to 25 °. for both SLR and HD cameras such as Comodo; zcam-e2; For Sony a7s3 and For Panasonic S5, etc. With redundant configurations of ESC and motor
supported, best performance and security are both ensured. DJI FPV air unit digital VTx system installation seat has been reserved.
Two pieces of 5mm carbon fiber arms provide reliable structural support for this powerful quad. We also have new vesion Holybro KAKUTE F7 V1.5, KAKUTE F7 HDV,KAKUTE F7 Mini V3 which are compatible with X8.
Features:
Propeller: Gemfan 7040 7 Inch 3-Blade Propellers
Motor: For T-Motor F90 KV1300 Motors
Arm: 16mm wide x 10mm thick (with 5mm thick carbon fiber boards overlaid)
Landing gear: TPU bracket combined with 10 mm carbon fiber tube
Compatible with DJI Air Unit & Caddx Vista HD Digital System
Compatible with multiple mounting holes: 30.5x30.5mm & 20x20mm
Professional camera installation supported: Komodo, ZCAM, BMPCC, etc
Camera platform shock absorption structure with 10 silicone damping balls
Spacing between top and bottom plates: 22mm
Camera platform elevation: 0 ~ 25 ° Adjustable
Wheelbase: 396mm
Weight: 1124g
Frame weight: 640g
Recommended equipments:
FC:KAKUTE H7
ESC:Tekko32 F4 4in1 45A ESC / Tekko32 F4 Metal 4in1 65A ESC
VTx:DJI FPV Air Unit / CADDX Vista Kit
Battery Recommendation: 6s 5000mAh
Payload Capacity: 1.5kg
Flight Time: 5 minutes (with 1.5kg payload)
11 minutes (without payload)
Note:Flight time was tested using 6s 5000mAh battery with 2806.5 1300kv
motor & 7040 props. Flight time may vary depending on payload and
battery size.
Includes:
1x Kopis Cinematic x8 Frame Kit
8x T-motor F90 KV1300 Motors(Optional)
12x Gemfan 7040 7 Inch 3-Blade Propeller(Optional)
