Tech Specs
Mic Input
Frequency Response
22Hz to 20kHz (+/-0.2dB)
Dynamic Range
90dB, A-weighted
Signal-to-Noise Ratio
-90dB, A-weighted
THD+N
<0.0061% (-86dB)
Crosstalk
-85dB @ 1kHz
Input Impedance:Mic in
1.8K Ohms, typical
Adjustable Gain
+39dB
Inst Input
Frequency Response
22Hz to 20kHz (+/-0.2dB)
Dynamic Range
90dB, A-weighted
Signal-to-Noise Ratio
-90dB, A-weighted
THD+N
<0.0061% (-86dB)
Crosstalk
-75dB @ 1kHz
Input Impedance: Inst in
500K Ohms, typical;
Total Gain Range
+38dB
Line Inputs (RCA IN, Unbalanced)
Frequency Response
22Hz to 20kHz (+/-0.2dB)
Dynamic Range
90dB, A-weighted
Signal-to-Noise Ratio
-90dB, A-weighted
THD+N
<0.003% (-86dB)
Crosstalk
-90dB @ 1kHz
Input Impedance
10K Ohms, typical
Adjustable Gain
+8dB
Line Outputs 1/2 (Stereo, Unbalanced)
Frequency Response
22Hz to 20kHz (+/-0.2dB)
Dynamic Range
90dB, A-weighted
Signal-to-Noise Ratio
-90dB, A-weighted
THD+N
<0.003% (-86 dB)
Crosstalk
-90dB @ 1kHz
Nominal Output Level
Unbalanced: +2dBV, typical;
Headphone Outputs:
(at Maximum Volume; Into 100 Ohm load)
Frequency Response
22Hz to 20kHz (+/-0.2dB)
Power into Ohms
20 mW into 100 Ohms
THD+N
<0.06% (-66dB)
Signal-to-Noise Ratio
-90dB, A-weighted
Max Output Level into 100 Ohms
+2.0dBV, typical
Load Impedance
32 to 600 Ohms
Weight
0.518 KG（1.14lb）
Dimensions
150mm(L)x151mm(W)x56mm(H)
Dimensions
5.9"(L)x5.94"(W)x2.2"(H)
Downloads
UPod Live Quickstart
UPod Live Manual-English
UPod Live Manual-French
UPod Live Manual-German
UPod Live Manual-Italian
UPod Live Manual-Japanese
UPod Live Manual-Spanish
UPod Live Manual-Chinese
OS Compatibility
macOS 11.1 Big Sur
Yes
macOS 10.14 Catalina
Yes
macOS 10.13 High Sierra
Yes
macOS 10.12 Sierra
Yes
Mac OS X 10.11 El Capitan
Yes
Mac OS X 10.10 Yosemite and older
No
Android
Yes
iOS 11 - iOS 14
Yes
Windows 10
Yes
Windows 8.1
Yes
Windows 8
Yes
Windows 7
Yes
Windows Vista
No
Windows XP
No
