Product Name
|
|
|
|
Model
|
TA13
|
|
|
System Configuratio Specifications
|
|
|
|
Processor
|
MT6762V/WB(Octa-core，4*A53 2.0GHz)
|
|
|
Operating System
|
Android 9.0
|
|
|
Memory
|
16 GB ROM+2 GB RAM(Standard)
|
|
|
Expansion Slot
|
Micro SD card (Up to 64GB SDHC）
|
|
|
Display
|
4.0"，WVGA，800*480, IPS
|
|
|
Touch Panel
|
Capacitive touch panel
|
|
|
Front Camera
|
N/A
|
|
|
Rear Camera
|
5MP, AF, with flash LED
|
|
|
Touch Glas
|
Tempered glass
|
|
|
Keypad
|
22 physical keyboard keys on the front 1 power key, 2 scan keys on the side;
|
|
|
Battery Capacity
|
5000mAh removable lithium polymer battery
|
|
|
Fast charge
|
5V/2A
|
|
|
Speaker
|
3413 big speaker
|
|
|
Prompt
|
Vibration prompt /LED prompt/audio prompt
|
|
|
Vibration
|
Built-in vibration motor
|
|
|
Sensor
|
G-sensor
|
|
|
Communication Transmission
|
|
|
|
Wireless WAN (Network frequency）
|
GSM(B3/B5/B8)
TD-SCDMA：B34/B39
WCDMA：B1/B8
TDD-LTE Bands：B38/B39/B40/B41
LTE-FDD Bands：B1/B3
Optional for other special Band
|
|
|
Wireless WAN (Data Service）
|
GSM/TD-SCDMA/WCDMA/TDD-LTE/FDD-LTE
|
|
|
Wireless LAN
|
Wi-Fi 802.11 a/b/g/n/ac/k/v/r(Dual bands： 2.4GHz+5GHz)
|
|
|
Bluetooth
|
Bluetooth 5.0
|
|
|
GPS
|
Support GPS/AGPS/Glonass/BDS
|
|
|
1D/2D Barcode Scanning
|
|
|
|
Scan engine
|
Professional scanner SE6100-2D （developed together with Zebra）
|
|
|
Optical resolution
|
1280*800 Pixes
|
|
|
Scan precision
|
≥3mil , Code 39/128
|
|
|
Scan Angles
|
Tilt:360°，Pitch:±45°，Skew:±60°
|
|
|
Laser Safety Grade
|
Class II
|
|
|
NFC (Optional)
|
|
|
|
Frequency
|
13.56 MHz
|
|
|
Reading Distance
|
Within 2cm
|
|
|
Protocol
|
ISO14443A/ISO14443B
|
|
|
Special feature
|
Support contactless CPU card, support 2 generation ID card read
|
|
|
User Environment
|
|
|
|
Operating Temp.
|
-20~55°
|
|
|
Storage Temp.
|
-40~60°
|
|
|
Humidity
|
0~95%
|
|
|
Drop Specification
|
Marble 2M ，Concrete 1.5M
|
|
|
IP Grade
|
IP67
|
|
|
ESD
|
±12 KV air discharge；
±8 KV conductive discharge
|
|
|
Input / Output Ports
|
|
|
|
USB Port
|
1 PCS，Type-C USB waterproof port
|
|
|
Charger Port
|
1 PCS, Type-C USB waterproof port
|
|
|
OTG
|
Support
|
|
|
Develop Tools
|
|
|
|
Developing Tool
|
Android SDK
|
|
|
Supported language
|
Java
|
|
|
Accessories
|
|
|
|
Standard
|
Power adapter、USB cable、Battery， Lanyard，tempered glass screen protector
|
|
|
Optional
|
Desktop charger (Optional)
|
|
|
Mechanical Parameter
|
|
|
|
Dimension(LxWxD)
|
159mm*70.8mm*17.85mm
|
|
|
Weight
|
260g（Battery included ）
|
|
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
