1. Comprehensive Vector Network Analysis: The NanoVNA V2 3G is a powerful vector network analyzer capable of measuring and analyzing S-parameters (scattering parameters), including amplitude and phase information, making it an essential tool for any vector network analyzer application.
2. Wide Frequency Range: This hf vhf uhf vna covers a broad frequency range from 50kHz to 3GHz, encompassing a wide array of radio communication bands, ensuring versatile usage for various testing needs.
3. Portable and Convenient: Designed with portability in mind, the NanoVNA V2 3G is a compact and lightweight antenna analyzer, making it perfect for outdoor, laboratory, and mobile scenarios, offering ease of transport and use.
4. High Precision Measurements: This handheld vector network analyzer boasts high precision measurement capabilities, delivering low-loss and high dynamic range results, ideal for accurate and reliable testing.
5. Open Source and Versatile Applications: As an open-source project, the NanoVNA V2 3G's hardware and software designs are publicly available, making it a versatile vna analyzer for applications in radio communication, RF circuit design, antenna analysis, and filter design.
Specification:
Origin: Mainland China
Frequency range: 50kHz-3GHz
Frequency error: 2ppm
Frequency temperature: 0.5ppm
System dynamic range (calibrated): 70dB (up to 1.5GHz), 60dB (up to 3GHz)
Scan speed: 100 points/second
Display: SAA2 2.8-inch, 320 x 240; SAA2N 3.95-inch, 320 x 480
RF port: SAA2 SMA; SAA2N N
(If you need to measure pin-proof SMA devices such as Wi-Fi antennas, please use SMA to RPSMA connector)
USB interface: microUSB
Power supply: USB, maximum charging current 1A
Battery: SAA2 2000mAh Li-ion; SAA2N 3000mAh Li-ion
Battery connector: JST-XH 2.54mm
Maximum scan points (on device screen): 201
Maximum scan points (USB): 1024
Port 2 return loss (1.5GHz): 20dB typical
Port 2 return loss (3GHz): 13dB MIN
VNA-QT software compatible systems: Compatible with Linux/Windows (7+)/Mac OS planned
Nanovna-saver: https://github.com/NanoVNA-Saver/nanovna-saver/releases
VNA-QT software download: https://github.com/mdkendall/NanoVNA-QT/releases/
