PCI-E to 4-port R232 expansion card

Gold finger thickened gold plating design, scratch and wear resistant, more firm contact and more stable transmission

The powerful chip adopts aszx AsiaInfo master control, with high-speed and stable transmission

Supporting 4-port RS-232 serial port cable, it can connect a variety of serial port devices, such as PC, terminal, modem, printer, scanner, etc. the data rate of each port can reach 115200kbps

Pce4sop-a01 is a universal-purpose PCE serial port card, which is designed for POS, ATM and other applications. It can be used for industrial automation system manufacturing and system integration. Pceasop. - A01 provides four RS232 serial ports, which can connect a variety of serial port devices, such as PC, terminal, modem, printer, scanner, etc.

Model: pec4s0p-a01

Interface: pce-e 1x (compatible with 1X, 4x, 8x, 16x)

Main control chip: Asix ax99100

Output interface: DB25 to 4 ports DB9 R232

2U small chassis: support, with half height baffle

Working environment: - 30-70 ℃

System support: WinXP win7 win8 win10 Linux

Single-lane (X1) PCI Express End-point Controller with PHY integrated

Compliant with PCI Express 2.0 Gen 1

Compliant with PCI Express card specifications

Compliant with PCI Power Management 1.2

Supports four PCI Express functions

Supports both legacy and MSI Interrupt

Supports ASPM Power Management

Serial Port Interface

Dual or Quad UARTs

Bi-directional speeds up to 25 Mbps per port

Full Serial Modem Control

Supports Hardware, Software Flow Control

Supports 5, 6, 7, 8 and 9-bit Serial format

Supports Even, Odd, None, Space and Mark parity

Supports Custom baud rate by internal PLL or external clock

Supports On Chip 256 Byte depth FIFOs in Transmit, Receive path of each Serial Port

Supports remote wakeup and power management features

Serial Port transceiver shutdown support

Supports multi-drop application for 9-bit mode

Supports DMA burst transfer

colour: black

Material: metal

Size: 12.5x10.5x2.5CM

Package Contents:

1 x R232 expansion card

1 x Drive CD

1 x DB25 to 4 DB9 data cables

Only the above package content, other products are not included.

Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
