Features:

* Be compatible with four standards of ISO, DIN, ANSI and JIS.

* Multiple parameter measurement: Ra, Rz, Rq, Rt.

* Highly sophisticated inductance sensor.

* Four wave filtering methods : RC, PC-RC, GAUSS and D-P.

* Small in size, light in weight and easy to use.

* Manual or automatic shut down.

* Can memorize 7 groups of measurement results and measuring conditions for later use or download to PC.

* Metric /Imperial Conversion.

* Use USB/RS-232 data output to connect with PC.

* Provide Bluetooth data output choice.

Principle:

When measuring the roughness of a surface, the sensor is placed on the surface and then uniformly slides along the

surface by driving the mechanism inside the tester. The sensor gets the surface roughness by the sharp built-in probe.

This roughness causes displacement of the probe which results in change of inductive amount of induction coils so as

to generate analogue signal, which is in proportion to the surface roughness at output end of phase-sensitive rectifier.

The exclusive DSP processes and calculates and then outputs the measurement results on LCD.

Specifications:

      Display

     4 digits, 10 mm LCD, with blue backlight

         Parameters

     Ra,Rz,Rq,Rt

                  Measuring Range

              Ra , Rq : 0.05~10.00 um / 1.000~400.0 uinch

           Rz , Rt : 0.020~100.0 um / 0.780~4000 uinch

         Accuracy

     ≤ ± 10%

         Fluctuation of display value

     Not more than 6%

         Sensor

     Test Principle

     Inductance type

         Radius of Probe Pin

     10 um

         Material of Probe Pin

     Diamond

         Measurement Force of Probe

     16 mN(1.6 gf)

         Probe Angle

     90°

         Vertical Radius of Guiding Head

     48 mm

         Maximum driving stroke

     17.5 mm / 0.7 inch

         Cutoff length (l)

     0.25 mm / 0.8 mm / 2.5 mm optional

         Driving speed

     Sampling

     When Length = 0.25 mm, Vt = 0.135 mm/s

         When Length = 0.8 mm, Vt = 0.5 mm/s

         When Length = 2.5 mm, Vt = 1 mm/s

         Returning

     Vt = 1 mm/s

         Resolution

     0.001 um, if reading < 10um

         0.01 um, if 10um ≤ reading ≤ 100um

         0.1 um, if reading ≥ 100um

         Evaluation length

     1~5 L optional

         Auto Power Off

         Operating conditions

     Temperature: 0~50 ℃   Humidity: < 80 %RH

         Power Supply

     4 x 1.5v AAA size (UM-4) battery

         Dimensions

     Main Unit

     149 x 67 x 29 mm

         Measuring Base

     185 x 56 x 47 mm

         Weight

     485 g

Standard Accessories:

*Main Unit

*Small Screwdriver

*Power Adapter

*Standard Sample Plate

*Standard Sensor

*Adjustable Leg

*Sheath of Sensor

*Carrying Case

*Instruction Manual

Optional Accessories:

*Groove Stylus SRP-110

*Curvature Probe SRP-120

*Extension Rod SER-150

*Measurement Stand SRS-1

*USB, RS-232C data cable with software

*Bluetooth data out put with software

Comparation of similar products SRT-6210S and SRT-6200S:
