Features:

* Be compatible with four standards of ISO, DIN, ANSI and JIS.

* Multiple parameter measurement: Ra, Rz, Rq, Rt.

* Highly sophisticated inductance sensor.

* Four wave filtering methods : RC, PC-RC, GAUSS and D-P.

* Small in size, light in weight and easy to use.

* Manual or automatic shut down.

* Can memorize 7 groups of measurement results and measuring conditions for later use or download to PC.

* Metric /Imperial Conversion.

* Use USB/RS-232 data output to connect with PC.(Optional)

* Provide Bluetooth data output choice.(Optional)

Principle:

When measuring the roughness of a surface, the sensor is placed on the surface and then uniformly slides along the surface by driving the mechanism inside the tester. The sensor gets the surface roughness by the sharp built-in probe. This roughness causes displacement of the probe which results in change of inductive amount of induction coils so as to generate analogue signal, which is in proportion to the surface roughness at output end of phase-sensitive rectifier. The exclusive DSP processes and calculates and then outputs the measurement results on LCD.

Specifications:

      Standards

   GB/T6062,ISO4287,DIN4768,JIS B,ANSI46.1

       Parameters

   Ra,Rq,Rz,Rt

       Measuring Range

   Ra:0.05~10.00µm/1.000~400.0µinch        Rz:0.020~100.0µm/0.780~4000µinch

       Accuracy

   <<±10%

       Fluctuation of Display Value

   <<6%

       Resolution

   0.001/0.01/0.1

       Sensor

   Radius of Probe Pin

   10µm

       Material of Probe Pin

   Diamond

       Measurement Force of Probe

   16mN(1.6gf)

       Probe Angle

   90º

       Vertical Radius of Guiding Head

   48 mm

       Maximum Driving Stroke

   17.5mm/0.7inch

       Cutoff length(l)

   0.25mm,0.8mm,2.5mm

       Driving Speed

   Sampling

   When Length=0.25mm,Vt=0.135 mm/s

       When Length=0.8mm,Vt=0.5mm/s

       When Length=2.5mm,Vt=1mm/s

       Returning

   Vt=1mm/s

       Profile Digital Filter

   RC,PC-RC,GAUSS,D-P

       Evaluation Length

   1L~5L Optional

       Data Memorize

   7 Groups

       Operating Conditions

   Temp:0ºC~50ºC   Humidity:<80%RH

       Power Supply

   4x1.5V AAA(UM-4)Battery

       Size

   Main Unit Size:149mmx67mmx29mm

Measuring Base Size:185mmx56mmx47mm

       Weight

   485g

       Standard Accessories

   Main Unit

       Standard Sample Plate SSP-100

       Standard Sensor SSP-100

       Small Screwdriver

       Measuring Base

       Carrying Case ( B09 )

       Operation Manual

       Optinal Accessories

   RS-232C Cable with Software

       Bluetooth Adapter with Software

       Extension Rod SER-150

       Groove Stylus SRP-110

       Curvature Probe SRP-120

       Measurement Stand SRS-1
