Podcast Station with built-in Recorder / USB Audio Interface

Mixcast 4

Podcast audio creation made easy

Mixcast 4 makes professional content creation easy. For Podcast creation, live streaming, event production, or voice over, Mixcast 4 will mix and record mic inputs, internal sounds and music via the trigger pads, and external audio input from your phone or PC. Together with the TASCAM Podcast Editor software, a complete solution - including both waveform editing and sound pad control - is provided from pre-production to completion.

 Improve your production workflow and inspiration

 The Mixcast 4 is a one-stop workstation that allows for the recording and mixing of sound sources without complicated settings. It provides all audio-related operation and workflow needed for live-streaming, events, podcasts, and other applications. The bundled TASCAM Podcast Editor software will expand the ability to assign content and sound effects to the internal touchpads, and will allow for smooth and easy remote track arming, effects assignment, audio editing and more without the need for expertise and complexity.

FEATURES

Stress-free touch panel control

  Equipped with 4 mic inputs and 4 individual headphone outputs, the Mixcast 4 is always ready for production thanks to the installed auto-mixing function that will automatically adjust optimal levels and set mic priority with no troublesome configuration for a perfect mix. The Mixcast 4 also showcases a 5-inch color touch screen that provides quick and intuitive access to desired menu control settings.

 One-stop workstation with a variety of functions

 From audio recording to the mixing of recorded audio, the Mixcast 4 offers a one-stop solution with multiple convenient functions such as 14-track multi-track recording direct to the unit's SD card, Bluetooth®, an AUX IN (3.5mm) connection to easily mix and record phone conversations/sound sources, and PC connectivity that allows the unit to import sounds from a computer.

Enhance content with real-time sound effects

The Mixcast 4 comes with fully customizable sound pads. In addition to preset sound effects, users can flexibly assign new sounds or even pre-recorded mic sounds that have been recorded on the unit. The Mixcast 4 sound pads also allow for easy and on-time voice effects such as voice transformation, reverb, and more to make live-streams and recordings even more interesting and fun.

Bundled with TASCAM Podcast Editor dedicated software

The TASCAM Podcast Editor offers simple and practical editing of audio content, track arming, as well as easy configuration and assignment of sound effects and background music to the sound pads. There's no need for expert knowledge on DAW software as the TASCAM Podcast Editor also offers intuitive graphics that will help users record audio easily using the Mixcast 4. TASCAM Podcast Editor is designed specifically for Mixcast 4, and seamlessly integrates together for a total production environment.

Features at a glance

      Podcast production of up to 4 people: 4 mic inputs with auto-mix, 4 headphone outputs

   Invite guests and friends: Mix-Minus to connect call-ins with echo-free audio via Bluetooth, USB input or 4-pole TRRS audio cable

   Sound pads for instant sound triggering and effects

   Easy and intuitive control using the 5-inch touch panel

   Fully compatible with the dedicated TASCAM Podcast Editor software to cover the entire production workflow

   Direct internal multi-track recording to SD card (up to 14 tracks)

   14in/2out USB audio interface

   Nine language options including English, French, German, Italian, Spanish, Russian, Chinese, Japanese and Korean

Included Items

 Power adapter PS-P1220E NUT

 Owner's manual (warranty included)

Accessories

 Carrying bag for Mixcast 4 CS-PCAS20 (sold separately)

 Dynamic microphone for broadcast streaming TM-70 (sold separately)

Spec description

      Recorder specifications

       Recording media

   SD cards (64 MB to 2 GB), SDHC cards (4 GB to 32 GB), SDXC cards (48 GB to 512 GB)

       Recording/playback formats

       WAV(BWF)

   48 kHz, 24 bit, 2 ch Stereo/14 ch Poly

       Max. recordable tracks

   14 tracks (12 track + 2 mix)

       Analog audio input ratings

       MIC INPUT jacks (1-4)

       Connectors

   XLR/TRS combo jacks

       XLR

   XLR-3-31 (1: GND, 2: HOT, 3: COLD)

       TRS

   6.3mm (1/4") standard TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)

       Maximum input level

   +10 dBu (when LEVEL at min.)

       Nominal input level

   -10 dBu (when LEVEL at min.)

       Minimum input level

   -76.5 dBu (when LEVEL at max.)

       Gain range

   66.5 dB

       Input impedance

   2.1 kΩ

       PHONES (TRRS) 1 jack (CTIA standard)

       Connector

   3.5 mm (1/8") 4-pole mini jack

       Maximum input level

   +4 dBV (when LEVEL at min.)

       Nominal input level

   -16 dBV (when LEVEL at min.)

       Minimum input level

   -82.5 dBV (when LEVEL at max.)

       Gain range

   66.5 dB

       Input impedance

   2 kΩ

       LINE IN (TRRS) jack (CTIA standard)

       Connector

   3.5 mm (1/8") 4-pole mini jack

       Maximum input level

   +8 dBV

       Nominal input level

   -12 dBV

       Input impedance

   12 kΩ

       LINE IN L/R (balanced) jacks

       Connectors

   6.3mm (1/4") standard TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)

       Maximum input level

   +24 dBu

       Nominal input level

   +4 dBu

       Input impedance

   11 kΩ

       Analog audio output ratings

       PHONES jacks (1-4)

       Connectors

   6.3mm (1/4") standard stereo jacks

       Maximum output

   45 mW + 45 mW (0.1% THD+N or less, into 32Ω load)

       PHONES (TRRS) 1 jack (CTIA standard)

       Connector

   3.5 mm (1/8") 4-pole mini jack

PHONES (TRRS) 1 output splits from PHONES 1 output

       LINE OUT (TRRS) jack (CTIA standard)

       Connector

   3.5 mm (1/8") 4-pole mini jack

       Maximum output level

   -25 dBu

       Nominal output level

   -45 dBu

       Output impedance

   100 Ω

       MONITOR OUT L/R (balanced) jacks

       Connectors

   6.3mm (1/4") standard TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)

       Maximum output level

   +20 dBu

       Nominal output level

   +0 dBu

       Output impedance

   200 Ω

       LINE OUT jack

       Connector

   3.5mm (1/8") stereo mini jack

       Maximum output level

   +6 dBv

       Nominal output level

   -14 dBv

       Output impedance

   200 Ω

       USB specification

       Connector

   USB Type-C

       Format

   USB2.0 High-Speed, Mass-storage class/USB Audio Class 2.0(USB class-compliant)

       USB Audio

       Sampling Rate

   48 kHz

       Bit Depth

   24 bit

       Number of inputs

   14 channels *Output from this unit

       Number of outputs

   2 channels *Input to this unit

       Bluetooth®

       Output class

   2 (about 10m* unobstructed transmission distance)

       Supported profile

   A2DP

       Supported A2DP codecs

   SBC, AAC

       Supported A2DP content protection

   SCMS-T

       Recording times (in hours: minutes)

   Recording format: 24-bit / 48kHz WAV

14 ch: 0:35 (4 GB) / 1:10 (8 GB)

2 ch: 4:07 (4 GB) / 8:15 (8 GB)

The recording times shown above are not continuous recording times. They are total recordable times for SD/SDHC/SDXC cards.

       Power

   Dedicated AC adapter (PS-P1220E NUT), DC 12 V

       Power consumption

   12.5 W (maximum)

       Weight

   2.55 kg

       Operating temperature range

   0 - 40°C

       Dimensions

   374.8(W) × 56.5(H) × 263.6(D) mm (excluding protrusions)

374.8(W) × 71.2(H) × 266.7(D) mm (including protrusions)

       Include items

   AC adapter (PS-P1220E NUT), USB Type-C to Type-C cable, Owner's manual (inc. warranty)

* The transmission distance is an estimate. The transmission distance may vary depending on the surrounding environment and radio wave conditions.

Audio Performance

      Mic amp EIN (equivalent input noise)

   -125 dBu or less (150Ω termination, LEVEL at max.)

       Frequency response

   Mic input jacks (1-4)

20 Hz - 20 kHz: +0.3 dB / -0.3 dB (JEITA)

       S/N ratio

   101 dB( Mic input jacks (1-4), channel faders at 0, 20kHz SPCL LPF +A-Weight)

       Distortion

   0.003%

( Mic input jacks (1-4), 1kHz sine wave, channel faders at 0, 20kHz SPCL LPF)

       Crosstalk

   95 dB or more

Note: Measurement conditions conform to JEITA CP-2905B.

Supported OS'

Windows

Windows 11 , Windows 10 (November 2021 Update) , Windows 10 (May 2021 Update)

Mac

macOS Monterey , macOS Big Sur , macOS Catalina

iOS

iOS 15 , iPadOS 15 , iPadOS 14 , iOS 14 , iPadOS 13 , iOS 13
