XDUOO XD05 BAL USB DAC ES9038Q2M *2 XMOS XU208 Decoder Bluetooth 5.0 APTX LDAC 32Bit 768KHz DSD Headphone Amplifier

 Features:-

 >Premium Dual DAC Chipset featuring 2*ES9038Q2M DAC chips.

 >High-Performance XMOS XU208 USB Signal Receiver.

 >Qualcomm CSR8675 Bluetooth Chip.

 >Hi-Res Bluetooth V5.0 Connectivity.

 >Support Hi-res Wireless codecs such as LDAC, aptX HD, aptX LL, and more.

 >Two-level Gain switch (+6dB/+15dB).

 >AES/Co-axial/Optical input options.

 >USB Type-C input support.

 >Aux Input.

 >6.35mm Single-ended headphone output.

 >4.4mm Balanced headphone output.

 Technical Specifications:-

 >Battery: 3.8V/5000mAh.

 >Battery Life: USB IN: up to 9 hours, SPDIF IN: up to 15 hours, Aux IN: up to 24 hours.

 >0.91" OLED Display.

 >Supports Android/iOS devices, Windows/MAC systems.

 >Frequency Response Range(USB/SPDIF): 20Hz-20kHz.

 >Frequency Response Range(AMP): 10Hz-60kHz.

 >Sampling Rate Support(USB): PCM up to 32-Bit/768kHz, DSD up to DSD512 natively.

 >Sampling Rate Support(AES/Optical/Coaxial): PCM up to 24-Bit/192kHz, DSD up to DSD64.

 >Output Power(6.35mm): up to 1000mW(32Ω).

 >THD+N(6.35mm): 0.0015%@1kHz.

 >SNR(6.35mm): 115dB.

 >Crosstalk(6.35mm): ≥72dB.

 >Output Power(4.4mm): up to 1000mW(32Ω).

 >THD+N(4.4mm): 0.0008%@1kHz.

 >SNR(4.4mm): 117dB.

 >Crosstalk(4.4mm): ≥100dB.

 >Output Level(Aux): 2.0Vrms.

 >Size: 13cmx7.5cmx2.2cm.

 >Weight: 0.29Kg.

 Powerful Dual DAC Chipset:-

 xDuoo has equipped the XD-05 Balanced with a premium Dual DAC chipset featuring 2xES9038Q2M DAC chips. It provides outstanding hi-res audio signal decoding with super-clean background and ultra-low distortion. The DAC chip is paired with a premium XMOS XU208 USB signal receiver chip providing hi-res signal decoding up to 32-Bit/768kHz and DSD512 natively.

 Seamless Wireless Connectivity:-

 Featuring the flagship CSR8675 Bluetooth signal chip from Qualcomm, the xDuoo XD-05 Balanced provides a seamless wireless Bluetooth V5.0 connectivity with hi-res codecs support such as LDAC, AptX HD, AptX LL, AptX, and many more.

 Powerful Balanced Output:-

 xDuoo XD05 Bal as the name suggests features a fully balanced 4.4mm headphone output port. The device is equipped with a premium OP+BUF amplifier circuit providing a whooping 1000mW power at 32Ω of load. This much power is more than enough to power your power-hungry headphones and makes them shine with all their glory. With the balanced headphone output, the S/N and dynamics are greatly improved. Along with this balanced headphone out port, the XD-05 Bal also features a single-ended 6.35mm headphone output.

 OLED Display, Gain Switch, & Other Features:-

 The XD05 Bal houses plenty of more features such as OLED display, Digital Decoding Filters, Boost switch, two-way gain(+6/+15dB), premium build quality, and much more.

 Bare machine size/weight (net weight)

 13*7.5*2.2CM

 0.29kg

 Package size/weight (gross weight)

 25*16*5cm

 0.8kg

 Accessories in the package:

 Dual-head Type-C charging/data cable*1

 USBA to c☐ adapter,

 Double-head Type-c OTG cable*1

 Lightning to Type-C OTG cable*1

 AES line*1

 6.5 to 3.5mm headphone plug*1

 Op Amp Chip *2

 Screwdriver*1

 Screw *5

 Silicone foot pad*10

 Guangli Adhesive Sticker*1

 User Manual *1

 Warranty card*1
